Rigol VB1080 VSWR bridge, 2 GHz to 8 GHz and DSA800-VSWR software for Rigol Spectrum Analyzers
  • Rigol VB1080 VSWR bridge, 2 GHz to 8 GHz and DSA800-VSWR software for Rigol Spectrum Analyzers

Rigol VB1080 VSWR bridge, 2 GHz to 8 GHz and DSA800-VSWR software for Rigol Spectrum Analyzers

Art. nr: 71407
6 880 kr

Antal




Produktbeskrivning

VSWR Bridge and DSA800-VSWR software for Rigol Spectrum Analyzers.

The VB1080's range is from 2-8 GHz.



*SW does NOT work with DSA1000 Family.

Requires TG Option.



VB1080 is used in combination with the RIGOL DSA series spectrum analyzer to measure S11-related parameters (such as return loss, reflection coefficient and VSWR).



VB1080 provides three N (Female) connectors.



Typical Applications
- Measurement of the S11-related parameters of the filter, amplifier, mixer, etc.
- Resonant frequency and VSWR tests of the antenna.
