SRS SR600 Serien Programmerbara Filter

Art. nr: SRS SR600

Begär offert




Produktbeskrivning

The SR600 series consists of three dual-channel instruments.



Each instrument channel has a low-noise preamplifier, a precision high-pass or low-pass filter section, and an output amplifier.



The filters are 8-pole, 6-zero elliptic-type with 115 dB per octave rolloff, 0.1 dB of passband ripple, and 80 dB of stopband attenuation.

Cutoff frequencies can be set between 1 Hz and 100 kHz making the SR600 Series ideal for applications including anti-aliasing, audio analysis, and frequency-domain signal conditioning.



Model - Configuration

SR640 - dual low-pass
SR645 - dual high-pass
SR650 - high-pass/low-pass (can be cascaded for Band -pass)





Mer information

  • Two independent filter channels
  • 115 dB/octave rolloff
  • 1 Hz to 100 kHz frequency range
  • 0.1 dB passband ripple
  • 6 nV/√Hz input noise
  • Up to 80 dB of gain
  • GPIB and RS-232 interfaces
