Chroma 19020-serien Multi-kanals Högspänningsprovare

Art. nr: Chroma 19020

Begär offert




Produktbeskrivning

  • 10 channels in one device
  • 10 sets of sync output and measurement
  • ACWV/DCWV/IR 3-in-1 EST test
  • Master/Slave control up to 10 units
  • Programmable V-output and limits
  • OSC (Open/Short Check)
  • Flashover detection
  • 5kVAC & 6kVDC hipot test
  • 1MΩ~50GΩ insulation resistance test
  • Standard RS-232/Handler/GPIB interfaces
  • Large LCD panel
  • Panel lock function
  • CE mark

Applications:
  • Power cord
  • Capacitor
  • Resistance
  • Switch
  • Connector
  • Transformer
  • Charger
  • Adapter

Models & Accessories:
  • 19020 : Multi-Channel Hipot Tester (ACWV/DCWV/IR)
  • 19020-4 : Multi-Channel Hipot Tester (ACWV/DCWV/IR/4CH)
  • 19021 : Multi-Channel Hipot Tester (ACWV)
  • 19021-4 : Multi-Channel Hipot Tester (ACWV/4CH)
  • 19022 : Multi-Channel Hipot Tester (DCWV/IR)
  • 19022-4 : Multi-Channel Hipot Tester (DCWV/IR/4CH)
  • 19023-8-20 : Multi-Channel Hipot Tester(8kVAC/4CH)
  • A190200 : 19" Rack Mounting Kit for 19020 Series
  • A190201 : 3-way Scanner Box (10CH)
  • A190202 : 3-way Scanner Box (4CH)
  • A190203 : 19020 Series Hipot Tester software
* HV cable is optional for customized requirement



Mer information

High Efficiency Hipot Test Solution
The hipot test is one of the major test items in electrical safety testing. All electrical components and products including transformers, capacitors, power supplies, chargers, and home appliances require hipot testing.

With more than 3 decades of experience in developing instruments for test and measurement, Chroma created the 19020 Multi-Channel Hipot Tester with a brand new architecture. It can measure the hipot leakage current of all channels at the same time and conduct tests on up to 100 DUTs simultaneously.

Chroma 19020 saves space on the production line by eliminating the need to purchase multiple hipot testers. Its one-time multichannel test increases the efficiency of electrical safety testing. It improves manufacturing efficiency and reduces testing risks for products that require only hipot testing.

Chroma 19020 also has powerful functions for Flashover detection and Open/Short Check. With several international patents, it is the best tool for regulatory electrical hipot tests as it not only offers reliable quality, but also creates a highly efficient test platform.

World's First Sync Hipot Test (Patent Registered)
Chroma 19020 comes equipped with the world's first sync hipot test function. One single unit can operate 10 channels simultaneously with synchronized output and measurements. Up to 10 units (master & slave) can be linked to have 100 channels in total. These can be grouped for output as to avoid creating voltage differences caused by adjacent tests as well as to improve productivity.

Apply Chroma 19020 to various electrical products for quality assurance sampling, production line tests, and other previously time consuming testing demands.
