Rohde & Schwarz RTC-K2 UART/RS-232/RS-422/RS-485 Serial Triggering and Decoding
Bilder
  • Rohde & Schwarz RTC-K2 UART/RS-232/RS-422/RS-485 Serial Triggering and Decoding

Rohde & Schwarz RTC-K2 UART/RS-232/RS-422/RS-485 Serial Triggering and Decoding

Art. nr: Rohde & Schwarz RTC-K2
1 749 kr

Antal




Produktbeskrivning

  • Trigger on start, break, data and various error conditions
  • Telegram display as color-coded bus signals and in decode table
  • Supports decoding of up to 4 serial buses from analog or digital channel signals
  • On-screen serial decoding is time-correlated with the serial data waveform
  • Fastest UART and RS-232/RS-422/RS-485 eye-diagram mask testing with standard mask test functionality

All Rohde & Schwarz oscilloscopes support triggering and decoding of UART and of RS-232, RS-422 and RS-485 buses.



You set up decoding in seconds. For detailed analysis, results can be viewed as color-coded telegrams and/or in a table.



Errors are identified efficently and reliably using the hardware-accelerated trigger.



You can trigger on start, break, data and various error conditions
