Toellner TOE 8941-80 Linear Power Supply
1-channel power supply with 0–80 V and up to 5 A, 200 W output power, auto-ranging, CV/CC/CP mode, low ripple and remote control via analogue interfaces.
There are several varieties of this model, select in the list
The power supplies from the TOE 8941 series are suitable
for applications associated with:
- Research / development
- Laboratory / testing / experiments
- Production / test bays
- Quality assurance
- Service / training
Special features:
- Active wide range PFC: Input voltage 85 V to 265 V, 47 to 63 Hz
- Autoranging
- Can be used as constant voltage, constant current
and constant power source (CV/CC/CP) - Outputs at front; at rear as optionOn/Off switching of the outputs
- Sensing
- Analog interfaces included as standard
- USB, LAN or GPIB interfaces as option
- Free LabViewTM driver
- ½ 19" width, 2 HU design
- Parallel installation possible
Options:
- GPIB, USB and LAN interfaces
- Interlock
- Inhibit
- Power output at rea
Product information
-
Art.no
Toellner TOE 8941-80
