SRS CG635 Synthesized Clock Generator 1 Hz till 2.05 GHz

Art. nr: SRS CG635 Synthesized Clock Generator

Begär offert




Produktbeskrivning

  • Clocks from 1 µHz to 2.05 GHz
  • Random jitter <1 ps rms
  • 16 digits of frequency resolution
  • 80 ps rise and fall times
  • CMOS, PECL, ECL, LVDS, RS-485 outputs
  • Phase control and time modulation
  • PRBS for eye-pattern testing (opt.)
  • OCXO and rubidium timebase (opt.)


Mer information

The CG635 generates extremely stable square wave clocks between 1 µHz and 2.05 GHz.

The instruments high frequency resolution, low jitter, fast transition times, and flexible output levels make it ideal for use in the development and testing of virtually any digital component, system or network.



Clean clocks are critical in systems that use high-speed ADCs or DACs.

Spurious clock modulation and jitter create artifacts and noise in acquired signals and in reconstructed waveforms.

Clean clocks are also important in communications systems and networks.

Jitter, wander, or frequency offsets can lead to high bit error rates, or to a total loss of synchronization. The CG635 can provide the clean, stable clocks required for the most critical applications.
